Zyxel NR2301 5G NR Portable Router Sort5G NR Portable Router
5G NR Portable Router
The Zyxel Networks NR2301 is a cutting-edge 5G NR Portable Router that complies with the 3GPP Release 16 standard, ensuring seamless compatibility with 4G networks.
Offering high-speed broadband service through WiFi 6, it provides enhanced network security and supports up to 32 connected devices. With its compact design, your subscribers can stay connected on the go, enjoying unparalleled connectivity and convenience.
Lightning-fast 5G connectivity everywhere you go
The NR2301 has 5G NR DL speeds of up to 3.4 Gbps and 4G LTE DL speeds of up to 1.6 Gbps*, increasing internet speed and reducing network latency.
Wide spectrum bandwidth accelerates internet speeds and reduces network latency for premium and time-sensitive connectivity services.
WiFi 6 technology for superior performance and coverage
The NR2301 supports the WiFi 6 (11ax) standard, offering speeds of up to 1.8 Gbps with 2x2 UL/DL MU-MIMO. The uplink MU-MIMO, Orthogonal Frequency Division Multiple Access (OFDMA) and beamforming technologies empower the NR2301 to deliver premium speed for multi-streaming data access and optimal WiFi experience without dead zones.
Specifikationer:IP Networking
Supports IPv4/IPv6 dual stack (NDP IPv6)
DHCP Client/server
Supports ICMP
Virtual Private Network (VPN) passthrough
Supports NAT/NAPT
Supports DMZ
Supports DDNS
Routing
Supports Dynamic DNS for first APN
IP Firewall
Firewall can be enabled or disabled via GUI
Supports SPI firewall
Application-level firewall
Filters LAN MAC address
Filters LAN IP address
Supports port forwarding/triggering
Management
Supports local device management and firmware upgrade via Web GUI
PIN/PUK management
APN management
Operating frequency band selection
Supports UPnP IGD
FOTA remote firmware upgrade
Network selection
Data usage
WLAN feature
Filters LAN IP address
Wireless Protected Setup (WPS)
WiFi Multimedia (WMM)
Open, WPA2-PSK, WPA-PSK/WPA2-PSK, WPA3-SAE, WPA2-PSK/WPA3-SAE with AES security type
Multiple SSIDs/hide SSIDs
Supports MU-MIMO
WiFi-enabled devices: 32
Hardware specifications
5G NR interface
3GPP Release 16 standard-compliant
Supports DL 4×4 MIMO: n1/n3/n7/n38/n40/n41/n77/n78
Supports DL modulation QPSK, 16-QAM, 64-QAM and 256-QAM
Supports UL modulation QPSK, 16-QAM, 64-QAM and 256-QAM
Output power: Class 3 (23 dBm ± 2 dB)
Supports both NSA and SA modes
FDD: n1/n3/n5/n7/n8/n20/n28/n71/n75/n76/n77/n78
TDD: n38/n40/n41
Data rates:
5G NSA: DL 3.4 Gbps; UL 550 Mbps*
5G SA: DL 2.4 Gbps; UL 900 Mbps*
4G LTE interface
3GPP UE Category 19 standard-compliant
Supports DL 4×4 MIMO: B1/B3/B7/B38/B40/B41/B42/B43
Supports DL modulation QPSK, 16-QAM, 64-QAM and 256-QAM
Supports UL modulation QPSK, 16-QAM, 64-QAM and 256-QAM
Output power: Class 3 (23 dBm ± 2 dB)
Supports frequencies:
LTE-FDD: B1/B3/B5/B7/B8/B20/B28/B32
LTE-TDD: B38/B40/B41/B42/B43/B71
Peak data rates:
Max. DL 1.6 Gbps/UL 200 Mbps*
Wireless LAN Standards
802.11 a/b/g/n/ac/ax 2.4 GHz, data rate up to 574 Mbps*
802.11 a/n/ac/ax 5 GHz, data rate up to 1200 Mbps*
Hardware interface
One power on/off button
2.4" LED display
One type-c USB 3.1 quick charging
One reset button
One Nano-SIM card slot
One menu-confirm button
One menu-select button
Two TS9 external antenna connectors
Power consumption
15 W (5 V/3 A @QC)/18 W (9 V/2 A @PD 2.0) quick charging
Physical specifications
Item
Dimensions (WxDxH): 137.5 x 72 x 16.5 mm (5.41" x 2.83" x 0.65")
Weight: 196 g (0.43 lb.)
Packing
Dimensions (WxDxH): 173 x 100 x 47 mm (6.81" x 3.94" x 1.85")
Weight: 330 g (0.73 Ib.)
Environmental specifications
Operating
Temperature: 0°C to 40°C (32°F to 104°F)
Humidity: 5% to 95% (Non-condensing)
Storage
Temperature: -20°C to 60°C (-4°F to 140°F)
Humidity: 5% to 95% (Non-condensing)
Certifications
CE/Safety
WEEE
2011/65/EC (RoHS) Restriction of Hazardous Substances Directive
HSF (Hazardous Substance Free)
European Parliament and Council Directive 94/62/EC of 20 December 1994 on packaging and packaging waste
Package contents
Type-A to Type-C USB cable
Quick Start Guide
Safety warning
